Five Minute Design Patterns #1: The Builder Pattern

Welcome to the first of my Five Minute Design Patterns series where I take a brief look at a design pattern every week! The reason why I've gone for brief overviews is because I think sometimes, less can be more and not everyone always wants to be drowned in text & UML diagrams. My goal is to keep each one of these a maximum of a 5 minute read as per the calculation that can be seen under the blog title. This post will cover one of the Creational Patterns, namely the Builder Pattern. If you're looking for a post on one of the other of the Gang of Four Design Patterns, you will most likely find them here.

---

A Brief Overview

• The Builder Pattern is a Creational Design Pattern that aims to separate the construction of a complex object from its internal representation, instead facilitating a single/same construction process that can be used instead to create all of the different representations.

  • complex object - an object is considered complex when it can be resembled by numerous permutations, sometimes based on some sort of internal logic, also sometimes referred to as an aggregate. e.g. A car object is the complex object and examples of different representations could be... Silver Honda Civic, Red Honda Civic, Black Honda Accord.
  • internal representation - e.g. an object class, within a codebase.

By using this pattern, we can both simplify and refine the object construction process to allow easier creation of different permutations of the complex object, whilst also as a bonus, decreasing any code repetition and increasing code re-usability that may exist otherwise.

There are two common variations of this pattern, namely the Builder Pattern alongside the Fluent Builder Pattern.

The Builder Pattern vs. The Fluent Builder Pattern

The Builder Pattern will result in a Builder class alongside an optional BuilderDirector class. Either-or will contain methods that provide constructed objects and using these gets favoured over using the standard object constructor. Think of the Director class as an orchestrator that knows how to create pre-defined permutations using the Builder. Sometimes as you may have realised by now, you may just want to directly use the Builder yourself. In the below example, our BuilderDirector contains a pre-defined method that returns a Car object pre-configured to match that of a Silver Honda Civic.

var carBuilder = new CarBuilder(upgradeInventory);
var carBuilderDirector = new CarBuilderDirector(carBuilder);
Console.WriteLine(carBuilderDirector.BuildSilverHondaCivic().ToString());

Obviously it is possible to instantiate a new Car and pass parameters in to the constructor to construct our object, however at scale and with a large number of parameters, this becomes very tedious in a code base where we have to constantly instantiate different permutations of different cars, models, colours, specifications, etc. However on that note, do not go wild and suddenly convert every object instantiation to use this pattern. Use it as a tool, only where necessary.

The Fluent Builder Pattern provides the exact same functionality as the regular Builder Pattern, however with a fluent interface/API to help facilitate the construction process. This makes life particularly easier for developers going forward within the same codebase, particularly if they want to skip the middle man that is the Director.

In the below example our CarBuilder is a Fluent Builder and provides us with a fluent interface to configure and create the exact car we want.

var customCar = carBuilder
                    .WithMake(Brand.Nissan)
                    .WithModel("Skyline")
                    .WithNumberOfDoors(4)
                    .WithColour(Colour.Black)
                    .Build();

The fluent API is a lot nicer to use and as you see fit, the possibilities to abstract complexity is endless. For example, you could abstract a group of constructor parameters at once if it is logical to do so.

var customCar = carBuilder
                    .WithModel(Car.NissanSkyline)
                    .WithColour(Colour.Black)
                    .Build();

As a Skyline is always a Nissan and vice versa, along with always having four doors, it is possible to do something as the above. Within the above example, the WithModel(Car.NissanSkyline) method on the carBuilder somehow has been implemented to know that the enum Car.NissanSkyline needs to provide you a new Car with the correct brand, model and number of doors.

A Brief High Level Overview

Whilst UML class diagrams work well for Design Pattern overviews, as I said in the introduction, I'm looking to keep things simple and avoid them throughout this Five Minute Design Pattern series of blog posts.

Our Program can optionally depend on a CarBuilderDirector.

public class CarBuilderDirector
{
    private readonly ICarBuilder _carBuilder;

    public CarBuilderDirector(ICarBuilder carBuilder)
    {
        _carBuilder = carBuilder;
    }

    public Car BuildSilverHondaCivic()
    {
        _carBuilder
            .WithMake(Brand.Honda)
            .WithModel("Civic")
            .WithNumberOfDoors(4)
            .WithColour(Colour.Silver);

        return _carBuilder.Build();
    }

    public Car BuildRedToyotaYaris()
    {
        _carBuilder
            .WithMake(Brand.Toyota)
            .WithModel("Yaris")
            .WithNumberOfDoors(2)
            .WithColour(Colour.Red);

        return _carBuilder.Build();
    }
}

Within the below CarBuilder class we see one of the main perks of the Builder Pattern at play. We have some business logic that determines whether we can create a Car object with a specific upgrade, depending on whether it is in stock or not.

When not employing the Builder Pattern, we might usually see this sit within the constructor of the Car object. Therefore by using a CarBuilder, we can separate the complex construction of the object from its internal representation, as per our initial definition of this pattern.

public class CarBuilder : ICarBuilder
{
    private Car _car;
    private readonly IEnumerable<Upgrade> _upgradesInStock;

    public CarBuilder(IEnumerable<Upgrade> upgradesInStock)
    {
        ResetBuilder();
        _upgradesInStock = upgradesInStock;
    }

    public void ResetBuilder()
    {
        _car = new Car();
    }

    public ICarBuilder WithMake(Brand brand)
    {
        _car.SetBrand(brand);
        return this;
    }

    public ICarBuilder WithModel(string model)
    {
        _car.SetModel(model);
        return this;
    }

    public ICarBuilder WithNumberOfDoors(int numberOfDoors)
    {
        _car.SetNumberOfDoors(numberOfDoors);
        return this;
    }

    public ICarBuilder WithColour(Colour colour)
    {
        _car.SetColour(colour);
        return this;
    }

    // By using the Builder Pattern, we separate
    // this complex construction logic of the Car object
    // (which is based on whether an upgrade is in stock or not),
    // from the internal representation of the Car.
    public ICarBuilder WithUpgrade(Upgrade upgrade)
    {
        if (!_upgradesInStock.Contains(upgrade)) return this;
        _car.AddUpgrade(upgrade);
        return this;
    }

    public Car Build()
    {
        var builtCar = _car;
        ResetBuilder();
        return builtCar;
    }
}

Conclusion

TL;DR - If you find yourself with a complex object within your codebase that can be constructed in many different permutations and this is leading to lots of large constructors repeated everywhere and more headaches of that sort... then the Builder Pattern might be just what you're looking for.

If you spot any mistakes, do let me know in the comments below.

Source Code

In order to keep the blog posts within this series short and sweet, I've not dumped all of the source code on the posts. If you want to see the full working implementation of the above and explore it yourself, feel free to get the source code from the link below.

https://github.com/karam94/CSharpDesignPatterns/tree/main/Creational

Thanks for reading! 👋
